| Input
|
24 VDC ±20% at 6.1 A
|
| Output power rating -40° to 60°
|
+12 VDC at 8.0 A
|
| Output power rating 60° to 70°
|
+12 VDC at 6.0 A
|
| Inrush (soft start)
|
20 A peak maximum for 5 ms over the 24 VDC
input range (including 12 VDC output).
|
| Input protection
|
Internally fused; fuses cannot be replaced.
|
| Overvoltage protection
|
Output protected at 110% to 120%.
|
| Holdup time
|
Output remains with 5% of nominal at full
load and minimum input voltage for 5 ms .
|
| Heat dissipation
|
5.2 W
|
| Alarm relay connectors
|
- Alarm contacts:
2-wire normally open relays; relays are closed when 3.3 and 5 VDC outputs are
within ± 4% of nominal
- Alarm relay
contact rating: 30 VDC at 2.0 A; 250 VAC at 2.0 A
|
| Mounting
|
On either slot of the power/controller
carrier.
|
