Specifications
| Item | Specification |
|---|---|
| Maximum power requirement | 24 VDC ±10% at 85 mA with no load |
| Maximum heat dissipation | 1.9 W |
| Operating temperature | -40 to 70 °C |
| Storage temperature | -40 to 85 °C |
| Relative humidity | 5 to 95%, non-condensing |
| Protection from airborne contaminants | ISA-S71.04-1985 Airborne Contaminants Class G3 conformal coating |
| Shock | 10 g half-sine wave for 11 ms |
| Vibration | 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Ingress protection class | IP20 |
