| Item | Specification |
|---|---|
| Capacity | Eight I/O cards with terminal blocks. |
| Maximum current |
LocalBus (powers I/O cards): 15.0 A Bussed field power bus (shared by multiple I/O card pairs): 6.5 A @ 30 VDC or 250 VAC (for each connection) |
| LocalBus cable |
Bottom cable extender: 1.0 m (3.3 ft) nominal length Top cable extender: 2.0 m (6.6 ft) nominal length |
