| Item | Specification |
|---|---|
| Capacity | Eight I/O cards with terminal blocks or four Logic Solvers with terminal blocks |
| Maximum current |
LocalBus (powers I/O cards): 15.0 A Bussed field power (shared by multiple I/O cards): 3.25 A (for each card); 13.0 A (for a set of 4 cards) @ 30 VDC or 250 VAC |
| Carrier extender cable (includes 2 carrier extenders and cable) |
1.1 m (3.6 ft) standard .43 m (1.4 ft) |
