| Item | Specification |
|---|---|
| Input | 18.5 to 36 VDC (24 VDC nominal) |
| Output | 12 VDC ±5% |
| Output current | 5 A |
| Input to output isolation | 250 VAC rms |
| Holdup time | 1.8 ms |
| Input protection | Internally fused, non-replaceable fuses |
| Over voltage protection | 110% to 120% |
| Input power | 80 Watts |
| Mounting | I.S. Power Supply Carrier |
| External connectors | DC input 2-part screw terminal |
