Specifications
The following table show specifications for the I/O, Fused I/O, and
4-wire I/O terminal blocks.
Table: I/O, Fused I/O, and 4-Wire I/O Terminal Block
Specifications
| Item
|
Specification
|
| Voltage rating
|
I/O and fused I/O: 250 VAC and 60 VDC between
non-connected signals for I/O and fused I/O
4-wire I/O: 30 VDC
|
| Maximum current
|
1 A per I/O channel
|
| Mounting
|
Assigned slot of I/O carrier
|
