HP_MA3_CV_SL_ GEM class (High Performance MA3_CV_SL_analog)

Note:

This figure shows the GEM at a 200 percent magnification.

This GEM is used for analog indication with PID loops, AI indicators, and ALM function blocks. It is also used where general percent of scale is important, and vertical space on the display is limited but horizontal space is available.

The following list describes the major components that may be present on an HP_MA3_CV_SL_ GEM. Click a link to see a description of that component.

Combination bar graph

Data field

EU descriptor
