Item
Specification
Mode selection
Switch selectable between ETA and DTA operation. Incorrect switch position will cause bad status on SLS Discrete Input.
Diode rating
24 VDC ± 20% 5 A maximum (actual current depends upon actuator used)
Mounting
Per DIN 43729
