| Number of channels
|
Eight
|
| Isolation
|
Each channel is optically isolated from the
system and factory tested to 1500 VDC.
|
| Nominal signal range (span)
|
1 to 5 VDC
|
| Full signal range
|
0.25 to 5.64 VDC, with overrange checking
|
| Valid range for LED indication
|
0.18 to 5.77 VDC
|
| LocalBus current (12 VDC nominal), per card
|
- 100 mA typical
- 150 mA maximum
|
| Field circuit power, per card
|
100 mA (used on card) at 24 VDC (±10%)
|
| Input impedance
|
2 MΩ
|
| Accuracy over temperature range
|
0.1% of span
|
| Resolution
|
16 bits
|
| Repeatability
|
0.05% of span
|
| Rolloff frequency
|
- -3 dB at 1.3 Hz
- -25 dB at one-half
the sampling frequency
|
| Calibration
|
None required
|
| Optional fuse
|
2.0 A
|
| Mounting
|
Assigned slot of I/O carrier
|
